Electrical Parameters

Frequency Range : 2400-2500 MHz

Impedance : 50 Ω

Standing Wave Ratio < 2.5

Gain : 6.0 dBi

Polarization Mode : Vertical Polarization

Radiation Direction : Orientation

Lightning Protection : DC Grounding

Power Capacity : 50 W

Horizontal Beam Width : 360°

Vertical Beam Width : 22°

Mechanical Properties

Length : 500 MM

Connector : N-K

Material : Glass Fiber Reinforced Plastics
